Emmer Cutting Edge Blade en End Bits
2.It is verkrijgbaar in een compleet assortiment specificaties, geschikt voor alle soorten laders in binnen- en buitenland
Aanvraag sturen
Product Details ofEmmer Cutting Edge Blade en End Bits
Kenmerken van wiellader Cutting Edge Blade en End Bit
1.Materiaal van hoge kwaliteit: 30GrMoNi of 30MnB/22SiMn2
2.It is verkrijgbaar in een compleet assortiment specificaties, geschikt voor alle soorten laders in binnen- en buitenland
3.De wiellader snijkant biedt stabiele prestaties, goede anti-slijtage vermogen, en hoge prestaties-prijs verhouding
4.De snijkant van de wiellader ondergaat blussen en temperen, met prestaties tot aan de internationale standaard
5.It is geïnstalleerd met bouten, wat gemakkelijk en handig is
Deel nr. | Beschrijving | Grootte | Bout | Gaten | Gewicht (kg) | Modeltoepassing |
4T2307 | Snijkant | 633*330*35 | 1" | 6 | 53.1 | 9u |
4T2322 | Snijkant | 632*330*40 | 1" | 6 | 60 | 9u |
4T2233 | Snijkant | 2133*203*25 | 81.5 | |||
4T2242 | Snijkant | 2133*203*25 | 81.5 | |||
4T2244 | Snijkant | 1828*203*25 | 69.8 | |||
4T2309 | Snijkant | 1223*330*35 | 1" | 8 | 104.6 | 9S |
4T2315 | Snijkant | 1558*203*19 | 3/4" | 10 | 43.5 | 5A |
4T2863 | Snijkant | 1520*254*25 | 3/4" | 15 | 71.4 | D7A (D7A) |
4T2867 | Snijkant | 2040*254*25 | 7/8" | 13 | 95.9 | D8C |
4T2917 | Snijkant | 1357*254*19 | 7/8" | 9 | 46.3 | D7U |
4T2921 | Snijkant | 1062*254*19 | 7/8" | 7 | 37.2 | 814S-D7S |
4T2922 | Snijkant | 758*254*19 | 7/8" | 5 | 26.6 | D7S, 814S, 816S |
4T2948 | Snijkant | 1062*254*19 | 3/4" | 7 | 37.2 | D7A (D7A) |
4T2949 | Snijkant | 1520*254*19 | 3/4" | 15 | 53.3 | D7A (D7A) |
4T2952 | Snijkant | 802*254*19 | 3/4" | 5 | 28.1 | D6, D6H, D7U |
4T2985 | Snijkant | 802*254*25 | 3/4" | 5 | 37.7 | D6A, D6H, D7U |
4T2987 | Snijkant | 923*254*25 | 1" | 6 | 43.4 | D8K |
4T2988 | Snijkant | 1034*254*25 | 1" | 7 | 48.6 | D8K |
4T2989 | Snijkant | 1062*254*25 | 3/4" | 7 | 49.9 | D7A (D7A) |
4T2990 | Snijkant | 1112*254*25 | 3/4" | 7 | 52.3 | D7S |
4T2992 | Snijkant | 758*254*25 | 7/8" | 5 | 35.6 | D7S, 814S |
4T2993 | Snijkant | 1062*254*25 | 7/8" | 7 | 49.9 | |
4T2994 | Snijkant | 1215*254*25 | 1" | 8 | 56.5 | 8A |
4T3010 | Snijkant | 658*203*19 | 3/4" | 4 | D6, D6C, D6H | |
4T3011 | Snijkant | 1619*203*19 | 3/4" | 11 | D6. | |
4T3013 | Snijkant | 1009*203*19 | 3/4" | 7 | D5H, D6S | |
4T3017 | Snijkant | 2335*203*19 | 3/4" | 15 | D6S | |
4T3028 | Snijkant | 674*203*19 | 5/8" | 4 | D4E, D5 | |
4T4317 | Snijkant | 810*254*25 | 1" | 5 | D8 | |
7T6591 | Snijkant | 983*280*25 | 7/8" | 6 | 50.7 | D7RII, D7R, D7E, D7RIIXR, D7RLGP, D7RIILGP, D7H |
9W8656 | Snijkant | 779*280*35 | 7/8" | 5 | 54.3 | 8U |
9W1878 | Snijkant | 1229*254*19 | 3/4" | 8 | 43 | 6SU |
107-3475 | Snijkant | 922*254*45 | 7/8" | 6 | 74.2 | 8U |
107-3481 | Snijkant | 922*254*45 | 1" | 6 | 73.9 | 8U, 8A |
12F-70-31251 | Snijkant | 760*152*16 | 5/8" | 5 | 13.2 | D31A-17 |
12F-70-31261 | Snijkant | 914*152*16 | 5/8" | 6 | 15.9 | D31P |
14x-71-11310 | Snijkant | 1383*203*19 | 3/4" | 9 | 40 | D60A, D65A-8, D65E-12 |
14Y-71-11210 | Snijkant | 1660*203*19 | 3/4" | 11 | 47 | D65 |
130-70-41130 | Snijkant | 1350*203*19 | 3/4" | 9 | 38.2 | D53A-15 |
130-920-2180 | Snijkant | 1199*203*19 | 3/4" | 8 | 33.9 | D65P-6 |
144-70-11131 | Snijkant | 1660*203*19 | 3/4" | 11 | 45.4 | D58, D60, D65, D65 |
154-70-11313 | Snijkant | 1156*254*25 | 3/4" | 12 | 54.5 | D85A, D60A-6 |
154-70-11314 | Snijkant | 1157*254*25 | 3/4" | 8 | 54.4 | D85A, D60A-6 |
154-81-11191/90 | Snijkant | 838*254*25 | 3/4" | 6 | 39.4 | D85A-18 |
175-70-21115 | Snijkant | 1397*254*25 | 7/8" | 9 | 65.7 | D155A-1 |
175-70-26310 | Snijkant | 1064*254*25 | 7/8" | 7 | 49.4 | D135, D155 |
17A-71-11351 | Snijkant | 761*330*32 | 1" | 5 | 55 | D155A3 |
17M-71-21550 | Snijkant | 1088*330*30 | 1" | 7 | 79.3 | D275A-2 |
195-70-12492 | Snijkant | 1327*330*32 | 1" | 9 | 106.3 | D155A3 |
195-71-11654 | Snijkant | 1064*330*32 | 1" | 7 | 85.2 | D375A-1 |
195-71-51120 | Snijkant | 710*330*32 | 1" | 5 | 53 | D355A-1 |
198-71-11181 | Snijkant | 1192*406*40 | 1-1/4" | 8 | 143 | D375, D455 |
198-71-31540 | Snijkant | 861*406*45 | 1-1/4" | 5 | 111.6 | D475 |
198-71-31550 | Snijkant | 1192*406*45 | 1-1/4" | 8 | 158.8 | D475 |
198-72-11181 | Snijkant | 861*406*41 | 1-1/4" | 5 | 104.8 | D375A-1/2/3/5, D455A-1, WD900-3 |
1U0295 | Snijkant | 1025*280*25 | 1" | 3 | 49.4 | 916, 926, 953 |
1U4941 | Snijkant | 1039*330*35 | 1" | 7 | 90.5 | D9 |
1U4943 | Snijkant | 1353*330*35 | 1" | 9 | 117.8 | 9U, 8SU |
1U4944 | Snijkant | 633*330*35 | 1" | 6 | 53.1 | 9u |
232-70-12143 | Snijkant | 1828*152*16 | 13 | 34 | GD523A-1, GD525A-1, GD505R-2, GD623A-1, GD625A-1, GD605R-3, GD37-6H, GD40HT-2, GD655R-3 |
Deel nr. | Beschrijving | Grootte | Bout | Gaten | Gewicht (kg) | Modeltoepassing |
232-70-52190 | Eindbit | 485*229*13 | 11 | GD523A-1, GD525A-1, GD623A-1 | ||
234-70-12233 | Eindbit | 529*229*13 | 12 | GD705R-2 | ||
3G4282/5 | Eindbit | 425*203*19 | 3/4" | 4 | 11.5 | 5P |
3G7763/4 | Eindbit | 610*392*35 | 1-1/4" | 7 | 65 | 9U, 9SU |
3G8283/4 | Eindbit | 680*400*40 | 1" | 7 | 75.2 | 9U, 9C, 8U, 8SU |
3G8291/2 | Eindbit | 680*400*35 | 1" | 7 | 65.7 | 9U, 9A, 8U, 8SU |
3G8293/4 | Eindbit | 480*300*25 | 7/8" | 7 | 29.8 | 835, 834, 826, 825, 824, 816, 814, 7A, 7U, 7S-LGP, 7S, 7SU |
3G8297/8 | Eindbit | 415*245*25 | 3/4" | 6 | 17.4 | |
3G8301/2 | Eindbit | 480*300*29 | 1" | 7 | 29.5 | 8SU |
3G8315/6 | Eindbit | 480*300*29 | 7/8" | 7 | 29.8 | 835, 834, 826, 825, 824, 816, 814, 7A, 7U, 7S-LGP, 7S, 7SU |
3G8319/20 | Eindbit | 415*245*25 | 3/4" | 6 | 17.4 | 815S, 6S |
1U1545/46 | Eindbit | 680*370*40 | 1-1/4" | 7 | 67.6 | 9U, 9SU |
195-71-11173/11183 | Eindbit | 680*330*40 | 1" | 7 | 67 | D355A3 |
13F-Z27-1572/82 | Eindbit | 325*204*25 | 3/4" | 5 | 12.6 | D61 |
11G-71-31170(2) | Eindbit | 380*160*16 | 5/8" | 4 | 6.9 | D31A-17, D31P-18 |
112-946-1510(2) | Eindbit | 355*160*16 | 5/8" | 4 | 7.2 | D31E-18, D37E-2, D37P-2, D41P-3 |
17M-71-21930/40 | Eindbit | 698*387*40 | 1" | 7 | 70 | D155A3 |
175-71-22272/82 | Eindbit | 540*254*38 | 7/8" | 7 | 37.1 | D155A1, D155A2 |
175*70*21126/36 | Eindbit | 492*254*38 | 7/8" | 7 | 35 | D135A-2, D155A-2 |
150-70-21346/56 | Eindbit | 435*254*30 | 3/4" | 6 | 26.4 | D85A-18 |
144-70-11260/50 | Eindbit | 326*204*30 | 3/4" | 5 | 15.2 | D65A-8 |
144-70-11180/90 | Eindbit | 330*226*25 | 3/4" | 5 | 12.6 | D53A-17. D58E-1 |
144-70-11180/70 | Eindbit | 359*222*25 | 3/4" | 5 | 15.1 | D53A-17 |
140-70-11170/80 | Eindbit | 359*222*25 | 3/4" | 5 | 15.1 | D50A-16, D60A, D65A-8 |
Productgegevens
